Agilent N9030A PXA signal analyzer, 3Hz to 50GHz
Describe
Use PXA to drive your evolution
The Agilent N9030A PXA signal analyzer is a product with the highest performance among the Agilent X-series analyzers, and an innovative replacement product for your existing signal analyzer. It can provide up to 26.5 GHz frequency range, through optional measurement functions and hardware scalability to ensure current and future flexibility. The advanced performance, flexibility, functionality and scalability of PXA will help you achieve high-demand applications in various fields such as aerospace, defense, and commercial communications. In addition, the PXA analyzer also includes a wide range of remote language compatibility features, which can more easily replace the existing Agilent or HP high-performance signal analyzers.
As the flagship product of X-series signal analyzers, PXA signal analyzers have excellent performance that can reduce measurement uncertainty and display more signal details, providing up to 75 dB spurious-free dynamic range over a 140 MHz analysis bandwidth . Its industry-leading technical indicators include –129 dBc/Hz phase noise at 10 kHz offset (1 GHz), absolute amplitude accuracy of ±0.19 dB, and –172 at 2 GHz (using preamplifier and noise floor extension technology) Displayed average noise level (DANL) sensitivity in dBm.
We cannot predict the future, but Agilent can help you create the future with future-oriented test instruments. The X series is an evolutionary method of signal analysis using instruments, measurement methods and software. Its flexibility can meet your commercial and technical requirements in multiple products and projects-both now and in the future.
Main Specifications
Function
- 3 Hz to 3.6, 8.4, 13.6 or 26.5 GHz
- 10 MHz (standard), 25, 40, or 140 MHz analysis
- 12 cursors, cursor table and synchronous detector
- Bandwidth
performance
- ±0.19 dB absolute amplitude accuracy
- At 2 GHz, +21 dBm third-order intercept (TOI)
- -172 dBm display average noise level (DANL)
- -83 (-88 dBc rating) W-CDMA ACLR dynamic range (noise correction function activated)
Measurement applications and software
- Noise figure, impulse, phase noise, etc. X series advanced measurement application software
- Advanced analysis functions with more than 70 signal formats, and the software can run inside the PXA analyzer. 89600 Vector signal analysis software
- MATLAB? Data analysis software for general data analysis, display and measurement automation MATLAB software for the X series
- Automatic and communication interface
- Conforms to LXI Class C standards, SCPI and IVI-COM
- USB 2.0, 1000Base-T LAN, GPIB
- Programmable remote language compatible with PSA, 8566/68 and 856x
- Universal X series user interface/open Windows XP operating system
